ANF - Agitated Nutsche Filter

Fill and submit the following Online Form or Click on the icon to download icon fill form and mail to info@unifabultra.com

Company

Address

Project Engineer

Department

Project

Telephone

Telex/Fax

Website

1)

(i) Chemical Name and Formula of solid material in suspension in slurry

(ii) Chemical Name and Formula of liquid in slurry

2) Slurry Characteristics

Size of Reactor from which slurry is fed into the filter

m³

Volume

m³/batch

Bulk Density : approx

Kg/m³

Solid Contents

% by weight

Temp

℃

No. of batches desired per day

3) Filtrate

Name of Liquid

Composition

Bulk Density

Kg/m³

4) Cake/Solids

Wet Cake Volume/Batch

m³

Liquid contents

Product

Bulk Density

Kg/m³

Nature of Cake - Type Yes or No

Crystalline Particles

Amorphous Particles

Slimy Material

5) Cake Wash

Washing liquid used

Quantity per wash / litre

Temperature

No. of washes per batch

a. Please inform us the filtration time desired including washing

b. Which operation, namely filtration or washing takes more time?

Cake reslurry - Yes or No

6) Product Properties

e.g. toxicity, odour, filtering characteristics etc.

7) Special Requirements

e.g. for pharmaceutical products

8) Construction

8.1 Max. Height available

8.2 Type of filtration

Suction filtration

Pressure filtration at

8.3 Dismountable bottom/one piece construction

8.4 Filtration Medium

Porous plates, Material

Pre Size

Filter Cloth, Material

Type

Wire netting, Material

Mesh Size

Special

8.5 Discharge Door with Davit support or Discharge Valve for Cake Discharge

8.6 Material of Construction - Vessel

Stainless Steel - Grade

Alloys: Hastelloy C (B)

Carbon steel, rubber lined lining type

Carbon steel, glass lined

Carbon steel, clad with

Stainless Steel, grade

Alloys: Hastelloy C (B)

Lined with

8.7 Filter Cloth Support

Stainless steel grade

Alloy

Any Other

Joints & Gaskets Material

8.8 Stuffing box or mechanical seal

8.9 External heating / cooling coil

Yes or No

Temp °C

Pressure bar g

8.10 Bottom Valve for filtrate needed - Yes or No

9) Control Equipments

9.1 Hydraulic Power Pack for Cake Discharge Valve/ Hand operated Cake Discharge Valve/ Hydraulic Valves actuated electrically / pneu-matically /manually

9.2 Special Requirements

9.3 Electric motors / Drive

Supplied by customer

Supplied by UUTLLP

9.4 Requirements for electrical parts: Normal / Explosion Proof

Constant Speed Agitator

Variable Speed Agitator

PIV / frequency control

9.5 Control Panel

Supplied by UUTLLP/ customer

For manual operation

Programmable control

Computer controlled

9.6 Power Supply

Volts

Phases

Control

DC/AC

Air

bar g

10) Present method of Filtration for the Same Product

10.1 Type of Filter used

10.2 Size of Filter

10.3 Quantity of Slurry per Batch

10.4 Time taken for Filtration per Batch

10.5 Name & Quantity per Batch of Wash Liquor used

10.6 No. of Washings per Batch

10.7 Time takne per Washing

10.8 Difficulties encountered with present method of Filtration & Washing System

11) Tests on Pilot Plant Filter

Not Necessary

Already Made - Results

Desired Date

12) Remarks

13) Size of the batch can only be determined after we get results from you of your Pilot Plant trials, or we conduct the trials in our Pilot Plant. You will have to give us 250 litres of slurry for trials. We shall be charging a nominal sum of Rs. 9000/- towards cost of trials, which will be refunded in case we receive order. Also, please note that your materials should be sent to our factory at your cost and the same must be collected from our works after trial is over within a week. In case materials are not collected we shall arrange to send the same to you at your cost.

Please fill up the answers to all the questions. In any information asked for is not available, you should mention "Not Available" in the space provided for the answer. Besides, the information asked for, any other information you feel is relevant may also be furnished. This will enable us to design a most efficient Filter.

Note: If space provided for answering any question is not adequate, please reply in separate sheet and attach.

Date:

We request you to arrange for the trial charges on the day of the trial.

RVD - Rotary Vacuum Dryer

Fill and submit the following Online Form or Click on the icon to download icon fill form and mail to info@unifabultra.com

Company

Address

Project Engineer

Department

Project

Telephone

Telex/Fax

Website

A) (i) Chemical Name & Formula of solid material to be obtained from Dryer

(ii) Chemical Name & Formula of Solvent/s & moisture in the feed

(iii) Required capacity of Dryer in MT/per day of dry material

B) Feed

(i) Moisture Content in % by Weight

(ii) pH Value of Feed

(iii) Bulk Density of Feed in Kg/cu.m.

(iv) Particle Size of the Feed (Solids)

(v) Inlet temperature in °C

(vi) Are impurities present in the feed? If yes, name of impurities

(vii) Does the wet material have a tendency to become highly viscous during the course of drying? If so maximum viscosity in CP

(viii) Any other details about the feed that you may think important for selection and design of the Dryer (may be given on separate sheet of paper as Appendix)

(ix) Please inforrm us the drying time allowed / batch including loading and unloading

C) Solids

(i) Maximum permissible moisture content in Dried product % by weight

(ii) Desired solids discharge temperature °C

(iii) Bulk Density of Feed in Kg/cu.m.

(iv) Are Solids:

a. Hygroscopic

b. Abrasive

(v) Is dried product temperature sensitive if so, state the temperature °C

(vi) Particle size of dry material

(vii) Is the dried product:

a. Free Flowing powder?

b. Large sized solids in lump form?

c. Fibrous product

(viii) Does the product have a tendency of forming lumps or plastic paste during drying operation?

(ix) Does the product have a tendency of sticking to the walls?

(x) Does the dry product contain fine dust which can be entrained along with vapour into the vacuum line? If yes, size of the fine dust for determining the size of mesh for dust catcher

D) Solvents

(i) Is solvent to be recovered?

(ii) Maximum permissible solids in solvent

(iii) Solubility of solids in solvent

(iv) Boiling temperature of solvent/s in °C at 710mm Hg (Vacuum)

(v) Are solvent/s temperature sensitive? If so, state critical temperature in °C

E) Material of Construction

(i) Material of construction of contact surface of dryer as recommended by you

(ii) Material of construction of Condensor

a. Tubes

b. Shell

(iii) Material of construction of Receiver

F) Drying Process

(i) Whether batch or continuous

(ii) Operation prior to drying

(iii) Operation subsequent to drying

(iv) Heating facilities available steam / hot oil / hot water and its temperature and pressure

(v) Any preference of the type of Dryer whether Paddle, Double Cone, Tumbling or Hollow-shaft screw Dryer, and reasons thereof. Details may be given in another sheet as Appendix.

G) Present Method of Drying

(i) Please describe

(ii) Problems encountered in the present method

(iii) Can you supply samples of wet and dry material for carrying out experiments in our Pilot Plant? We shall require 125 litres of wet material

For our Rotary Vacuum Dryer, trial charges will be Rs. 10000/-. These charges will be refunded in case order results. Also, please note that your materials should be sent to our factory at your cost and the same must be collected from our works after trial is over within one week. In case materials are not collected we shall send the same to you at your cost.

H) Physical Data

Please furnish as much information as possible:

Description

Solids

Liquids

(i) Molecular Weight

(ii) Melting Point °C

(iii) Boiling Point °C

(iv) Decomposition in air at °C

(v) Decomposition under vacuum at °C

(vi) Latent heat of vapour Kcal/hr

(vii) Temperature at which sublimation takes place (if so) °C

(viii) Bulk density Kg/litre

(ix) Specific gravity

(x) Specific Heat

(xi) Flash Point ° C

(xii) Design for saturated steam Pressure

I) Drying Data

(i) Drying curve if available enclosed

Yes or No

(ii) Bound moisture in the solid by retention in capillaries, solution in cellular structures, solution within the solid or by chemical or physical absorption on the surface of the solid

(iii) Unbound moisture, if hygroscopic in excess of the equilibrium moisture content corresponding to the saturation humidity.

Note: If space provided for answering any question is not adequate, please reply in separate sheet and attach.

Date :

We request you to arrange for the trial charges on the day of the trial.
